EDM & DF Oil Stones

{Welcome to inquire}

  • EDM Series Oil Stones:
    Mainly used to remove the hardened surface layer after EDM processing of various modules.
  • DF Series Oil Stone:
    Mainly used in general mold machining mark removal and polishing operations.

EDM & DF Oil Stones



  • EDM Series Oil Stones:
    Remove hardened surfaces after EDM processing of various modules.
  • DF Series Oil Stone:
    For general mold machining mark removal and polishing operations.

shape . sizes . Grit

shapesizesGrit


Rectangle

EDM and DF Oil Stones_Rectangle

6 x 3 x 150 mm ( 1/4″ x 1/8″ x 6″ )#120 , #180 , #220 , #320 , #400 , #600 , #800 , #1000 , #1200
6 x 6 x 150 mm ( 1/4″ x 1/4″ x 6″ )
13 x 1.5 x 150 mm ( 1/2″ x 1/16″ x 6″ )
13 x 3 x 150 mm ( 1/2″ x 1/8″ x 6″ )
13 x 6 x 150 mm ( 1/2″ x 1/4″ x 6″ )
13 x 13 x 150 mm ( 1/2″ x 1/2″ x 6″ )
25 x 3 x 150 mm ( 1″ x 1/8″ x 6″ )
25 x 6 x 150 mm ( 1″ x 1/4″ x 6″ )
25 x 13 x 150 mm ( 1″ x 1/2″ x 6″ )
10 x 10 x 150 mm ( 3/8″ x 3/8″ x 6″ )
Circle

EDM and DF Oil Stones_Circle

6mm round x 150 mm ( 1/4″ round x 6″ )#120 , #180 , #220 , #320 , #400 , #600 , #800 , #1000 , #1200
Semicircle

EDM and DF Oil Stones_Semicircle

6mm half circle x 150 mm ( 1/4″ half circle x 6″ )#120 , #180 , #220 , #320 , #400 , #600 , #800 , #1000 , #1200
Triangle

EDM and DF Oil Stone_Triangle

6mm triangle x 150 mm ( 1/4″ triangle x 6″ )#120 , #180 , #220 , #320 , #400 , #600 , #800 , #1000 , #1200
  • The above specifications and particle sizes are standard products, if you have special needs for specifications or particle sizes, please contact us.
